Videojet 7510 Laser Engraving Machine

Laser Engraving Machine

The 7510 50-Watt fiber laser delivers advantaged performance for high contrast marking on robust plastic packaging, metal containers and other industrial products even at ultra-fast line speeds up to 440m/min. Specifically engineered for high speed beverage, pharmaceutical and extrusion manufacturers, the 7510 laser engraving machine delivers better mark quality, higher efficiency and a dramatically smaller marking unit than traditional solid state laser systems.

  • Videojet 7510 Fiber Laser Engraving Machine, Laser Engraver machine, Laaser engraving machine
  • Side View of Videojet 7510 Fiber Laser Engraving Machine, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving on Tube, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving on Tin Can, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving on Plastic Bottle Cap, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Laser Engraving Machine Touch Interface,Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving Machine, Laser Engraver machine, Laaser engraving machine
  • Side View of Videojet 7510 Fiber Laser Engraving Machine, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving on Tube, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving on Tin Can, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Fiber Laser Engraving on Plastic Bottle Cap, Laser Engraver machine, Laaser engraving machine
  • Videojet 7510 Laser Engraving Machine Touch Interface,Laser Engraver machine, Laaser engraving machine
Specification
Value
Laser Tube Ytterbium (Yb) pulsed fiber laser
Maximum Power 50-Watt
Laser Cooling Air Cooled
Maximum Line Speed 440m/min (1440ft/min)
Environmental Protection Marking Unit: IP54
Supply Unit: IP21
Beam Output Steered Beam
Laser Source Expected Life (MTBF) Up to 100,000 hours (MTBF)
Laser Wavelength Options 1.06µm - 1.07µm
Focal Distance Options 100/163/254/420mm (3.93/6.41/10/16.53in)
Maximum Mark Window 498.5 x 366.5 mm (19.62 x 14.43 in)
Standard I/O Connectivity Internal Terminal Connections
Standard User Interface Smartgraph PC software
Optional User Inteface CLARiTY Laser Controller
Certifications/Approvals CE TUV

Uptime advantage through highly efficient laser source
  • Maximum performance and laser source life expectancy up to 100,000 hours (mean time before failure)
  • Highly efficient air cooled laser source virtually eliminates maintenance intervals
  • 90% more energy efficient compared to predecessor 100W Nd:YAG laser systems
Increase productivity and mark more content at higher speeds
  • Optimized to mark-on-the-fly at line speeds up to 440m per minute
  • Large marking window provides more time to mark, increasing throughput and maximizing productivity
  • CLARiTY Laser Controller features built-in productivity tools to help identify the root cause of downtime events and make sustainable process improvements
Mark the right codes time after time
  • High precision scan head delivers consistent high quality codes across the entire mark window
  • CLARITY Laser Controller uses built-in Code Assurance software to help prevent operator coding errors
  • Permanent codes help assure product traceability and tamper-proofing
Simple usability and seamless integration
  • Compact mechanical design with two beam delivery options simplifies integration
  • Intuitive color, touchscreen interface option makes training and usability quick and easy
Laser Engraving Machine for Beverages
Laser Engraving Machine for Wire, Cable and Pipe, Laser Engraver machine, Laaser engraving machine

Additional Applications

Laser Engraving Machine for Pharmaceutical and Medical Devices, Laser Engraver machine, Laaser engraving machine
