Laser Marking Machines

Laser Marking Systems

Videojet is a world renowned manufacturer of Industrial laser printers and laser marking machines which are used majorly for a detailed, sharper and permanent marking on a variety of product substrates ranging from paper and plastic products to metallic parts. Such marking enables the customers to not only deal with counterfeits but also implement traceability for regulatory/supply chain tracking purposes.

Advantages:

• High Resolution Permanent marking with a capability to print a wide variety of codes viz. Alphanumeric, Logo, 100% scannable QR/2D/1D codes, etc.
• Highest marking speed in the industry: can be >2000 characters/sec*
• Minimal Variable cost as no fluids/consumables required to run the machine
• No restriction or no. of lines/font- can print anywhere within the marking window
• High uptime: less downtime due to maintenance, No wear/tear- contactless marking
• Ease of integration: BTU supports complex installations, Ethernet/IP™ and Profinet™ communication protocols supported

CO2 Laser Marking machine: Customers with simple code requirements such as serial numbers, time, date, QR codes, Bar codes and lot codes as well as many other code formats can benefit from CO2 laser marking technology. We can support a wide range of speed options.

Possible Applications: Mono-cartons, Shipper Cartons, Pet Bottles, PVC, Leather, Foam, PU, Coloured Glass Bottles like wine & Champagne, etc.

Model	3210	3140	3340	3640
Output Power	30W	10W	30W	60W
IP rating options	IP54	IP54, IP65	IP54, IP65	IP54, IP65
Wavelength options	9.3 μm, 10.2 μm, 10.6 μm	9.3um, 10.6um	9.3um, 10.2um, 10.6um	9.3um, 10.2um, 10.6um
Focal Distance Options	3 options 100 mm (3.93 in) – 200 mm (7.87 in)	18 options 64 mm (2.50 in) – 400 mm (15.75 in)	24 options 64 mm (2.50 in) – 600 mm (23.62 in)	24 options 64 mm (2.50 in) – 600 mm (23.62 in)
Maximum Mark Window	72 x 115 mm2 (2.83 x 4.53 in2)	485 x 351 mm (19.09 x 13.81 in)	601 x 440 mm (23.66 x 17.32 in)	601 x 440 mm (23.66 x 17.32 in)
Communication Protocols Supported	Ethernet, TCP/IP	RS232, Ethernet, Profinet™ , Ethernet/IP™	RS232, Ethernet, Profinet™ , Ethernet/IP™	RS232, Ethernet, Profinet™ , Ethernet/IP™
Certifications/Approvals	CE Compliance (no certification required): ROHS	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA

Fiber Laser Marking machine: Fiber Laser Marking Technology is used for a wide range of marking and coding applications such as Marking/Engraving/Coding/Etching of Alphanumeric, logos/graphics QR codes, 2D codes, Barcodes, etc.

Possible Applications: Metals, Plastics such as PP, ABS, PVC, PBT, PE etc., Coated Metals, Coated Glass, Fiber Glass, Laminates, PP labels, etc.

Model	7230/7330	7340/7440	7510	7610
Output Power	10W/20W	20W/30W	50W	100W
Wavelength	1.06um	1.06um	1.06um	1.06um
Maximum Mark Window	498.5 x 361.5 mm (19.62 x 14.23 in)	64.5 x 126.3 mm (2.54 x 4.97 in)	498.5 x 366.5 mm (19.62 x 14.43 in)	498.5 x 366.5 mm (19.62 x 14.43 in)
Communication Protocols Supported	RS232, Ethernet, Profinet™ , Ethernet/IP™	RS232, Ethernet, Profinet™ , Ethernet/IP™	RS232, Ethernet, Profinet™ , Ethernet/IP™	RS232, Ethernet, Profinet™ , Ethernet/IP™
IP Rating (Marking head)	IP54	IP69	IP54	IP54
Marking head weight (System weight)	4.4kg(22.9kg)	0.6kg (24kg)	7.6kg (26.4kg)	8kg (33kg)
Certifications/Approvals	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA	Certifications/Approval CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA

UV Laser Marking machine: The pharmaceutical, medical and cosmetic industries can utilize UV laser marking machines to deter tampering and counterfeiting, helping to ensure brand protection and traceability. Marking on Glass, LDPE, HDPE, Nylon, Plastic, All Types of Industrial Grade Plastics, etc. is done by the UV laser marking machine. The UV laser uses a 0.355um Wavelength to mark on substrates.
